Application:

             Powder Coatings
             Nonmetallic Minerals
             Agricultural Chemicals
             Fertilizers
             Insecticides and Pesticides
             Industrial special chemicals
             Fillers
             Clay
             Carbon & Graphite
             Herbs and Spices
             Paints, Pigments and Bleaching
              Agents
             Detergents
             Food Products and Colourings
             Animal Feed
             Fish Feed
             Resins and Waxes
             Cosmetics
             Pharmaceuticals  |
            |
          Features:

             Integral forced vortex classifier provides
              accurate control of product size with
              sharp cut-off
             Accurate and consistent product
              grading
             On-stream adjustment of product size
              by variable speed classifier rotor
             Controlled generation of superfines
             Feed via a secondary air inlet gives the
              ability to pre-classify prior to grinding
              and minimizes overgrinding and
              production of superfines

            Performance:


               Capacity 0,2 t/h up to 10 t/h
               Drive power for grinding rotor 3 kW
                up to 90 kW
               Drive power for classifier rotor 0,37 kW
                up to 11 kW
           |
